Hobbywing UBEC-10A 2-6S TL2268

  • Model: TL2268
  • Shipping Weight: 50g
  • 990 Units in Stock


Add to Cart:

product manual:
UBEC-10A [2-6S] external BEC new product, UBEC is an external DC voltage regulator device, which switches the power supply mode. The UBEC can obtain the DC voltage suitable for the receiver and other equipment from the 2-6S lithium battery pack and stably provide up to 10A output current. The UBEC can easily supply power to a variety of devices on remote control models, especially for large helicopters and large fixed-wing aircraft using multiple servos.
1, the use of high efficiency DC-DC regulator chip, conversion efficiency of more than 90%;
2, the output voltage adjustable fourth gear (5.0V / 6.0V / 7.4V / 8.4V), to meet a variety of voltage specifications of the steering gear to use;
3, two parallel output, can carry a larger current;
4, with BEC through protection, to avoid accidental damage in the UBEC input voltage straight to the output and damage the receiver, steering gear and other equipment;
5, with overcurrent protection, the output short circuit protection, overheating protection and other functions, safe and reliable;
6, external switch, you can easily turn on and off UBEC;
7, exquisite metal shell, help to heat and reduce electromagnetic interference;
8, with the working status indicator, when the UBEC work is normal when the light is lit;
Product parameters:
Input voltage: 6V-25.2V (2-6S LiPo)
Output voltage: 5.0V / 6.0V / 7.4V / 8.4V (4 files adjustable)
Output current: continuous current 10A, instantaneous current 20A
Product Specifications:
Size: 43.1x32.3x12.5mm (L x W x H)
Weight: 36 grams
